Specifications
Weights
Gross Vehicle Weight Rating (lbs) | 14,500 |
Gross Combined Weight Rating (lbs) | 22,000 |
Measurements
Exterior Length (overall) | 24' 8" |
Exterior Width | 100' 0" |
Interior Height (main) | 84' 0" |
Tank Capacities
Fresh Water Capacity (gals) | 43.5 |
Gray Water Capacity (gals) | 40.0 |
Black Tank Capacity (gals) | 31.0 |
Fuel Tank Capacity (gals) | 55 |
Miscellaneous
Furnace BTU | 30000 |
Exterior Cargo Capacity (cu. ft.) | 24 |
2021 Redhawk
Starting at $99,893
Find out how Jayco’s legendary construction and unique standard features continue to make the reliable Redhawk one of the best values in its class.
