2022 Redhawk SE | 22A
2022 Redhawk SE
Previous model years are dealer stock only.
Interior Design
Blackstone
Exterior
Standard Graphics
Specifications
Weights
| Gross Vehicle Weight Rating (lbs) | 14,200 |
| Gross Combined Weight Rating (lbs) | 20,000 |
Measurements
| Exterior Length (overall) | 25' 2" |
| Exterior Height (with A/C) | 11' 6" |
| Exterior Width | 8' 4" |
| Exterior Width (with slides out) | 10' 2" |
| Interior Height (main) | 7' 0" |
| Awning Length | 16' 0" |
Tank Capacities
| Fresh Water Capacity (gals) | 43.0 |
| Gray Water Capacity (gals) | 40.0 |
| Black Tank Capacity (gals) | 32.0 |
| Propane Unit (lbs) | 41 |
| Fuel Tank Capacity (gals) | 57 |
Miscellaneous
| Sleeps | up to 5 |
| Tire Size | LT225/75R16E |
| Engine Size | 6L Vortec V8 |
| Exterior Cargo Capacity (cu. ft.) | 48 |
2022 Redhawk SE
Starting at $110,768
Built on the Chevrolet 4500 chassis, the 2022 Redhawk SE combines all the legendary construction elements Jayco is known for with features and designs selected specifically to enhance comfort on-the-road and at camp. The Redhawk SE is a great option for families or couples looking to give RVing a try, or switch from a towable for the first time.
