2023 North Point | 377RLBH
2023 North Point
Previous model years are dealer stock only.
See Floorplan with
an Option Added:
See Floorplan with
Virtual Floorplan Showings and Product Specifics Are Subject to Change Without Notice
Interior Design
Modern Farmhouse
Classic Cottage
Specifications
Weights
| Dry Hitch Weight (lbs) | 2,785 |
| Unloaded Vehicle Weight (lbs) | 14,410 |
| Cargo Carrying Capacity (lbs) | 2,585 |
| Gross Vehicle Weight Rating (lbs) | 16,995 |
Measurements
| Exterior Length (overall) | 42' 11" |
| Exterior Length (pin to bumper) | 41' 2" |
| Exterior Height | 12' 8" |
| Exterior Height (with A/C) | 13' 3" |
| Exterior Height (with 2nd A/C) | 13' 4" |
| Exterior Width | 8' 0" |
| Exterior Width (with slides out) | 14' 0" |
| Interior Height (main) | 6' 7" |
| Interior Height (upper deck) | 8' 6" |
| Awning Length | 11' 0" |
| Awning Length 2 | 20' 0" |
Tank Capacities
| Fresh Water Capacity (gals) | 75.0 |
| Gray Water Capacity (gals) | 87.0 |
| Black Tank Capacity (gals) | 50.0 |
| Propane Unit (lbs) | 60 |
| Propane Unit (lbs) (Optional) | 120 |
| Furnace, Auto-ignition (BTU output) | 40000 |
Miscellaneous
| Sleeps | up to 11 |
| Water Heater | 12 |
| # of outside storage compartments | 2 |
| Furnace BTU | 40000 |
| Tire Size | ST255/85R16'E' |
2023 North Point
Starting at $107,400
It’s the little things in this full-profile fifth wheel that you won’t find in others at the same price point. Like the new wooden pull-out spice rack and door with strut above the microwave. A new 24”x24” butcher block in the kitchen that flips up as a countertop extension and new 4K Smart TVs are just a few of the small details given attention in the 2023 North Point. Enjoy three-way adjustable headrests on theatre seats and a new pop-up charger with built-in wireless charger in the dining area for even more convenience and added comfort.
