See Floorplan with
Interior Design
Modern Farmhouse
American Craftsman
Specifications
Weights
Dry Hitch Weight (lbs) | 1,415 |
Unloaded Vehicle Weight (lbs) | 10,725 |
Cargo Carrying Capacity (lbs) | 1,525 |
Gross Vehicle Weight Rating (lbs) | 12,250 |
Measurements
Exterior Length (overall) | 40' 1" |
Exterior Height | 11' 7" |
Exterior Height (with A/C) | 12' 3" |
Exterior Width | 8' 1" |
Exterior Width (with slides out) | 2' 2" |
Interior Height (main) | 7' 4" |
Awning Length | 16' 0" |
Awning Length 2 | 9' 0" |
Tank Capacities
Fresh Water Capacity (gals) | 81.0 |
Gray Water Capacity (gals) | 74.0 |
Black Tank Capacity (gals) | 74.0 |
Propane Unit (lbs) | 60 |
Miscellaneous
Sleeps | up to 4 |
Water Heater | 6 |
# of outside storage compartments | 3 |
Furnace BTU | 32767 |
Tire Size | ST235/85R16 E |
2022 Eagle Travel Trailers
Starting at $75,218
Eagle is one of the longest-running, most successful RVs on the market and continues to be one of the most popular in its class year after year. Equipped with the very best features and full of innovation, the Eagle makes for a downright luxurious experience. The 2022 edition of the classic travel trailer features redesigned bathrooms, a smart TV upgrade and a new solar power option.
